Ranking of unmanned weighbridge systems in China?
The first process is shot blasting. For small manufacturers on the market, a shot blasting machine the cost of shot blasting and the expense of steel grit are very high, so small manufacturers in the market generally do not have the shot blasting process. The function of the shot blasting process is to remove foreign objects and oxide layers on the surface of the scale Wait to make the paint adhere better to the panel. Secondly, there is the paint. Currently, the paints used in the weighbridge industry on the market include epoxy paint, nano paint, and acrylic paint
It is recommended to choose epoxy paint as it has excellent anti-corrosion properties
The ability and adhesion are currently the best on the market, of course, the price and cost are relatively high.
One fatal problem with paint is that car weighing can cause the paint to wear off, and shot blasting
Its function is that it falls off bit by bit every day and will not cause large-scale shedding.
On top of this approach, WEIGHTWORTH has an exclusive anti-corrosion process in the weighbridge industry, using special high-molecular anti-corrosion paint
1.Strong corrosion resistance: It can be used for a long time in media such as acids, alkalis and salts. Tests have shown that this anti-corrosion coating can withstand 5% to 50% sulfuric acid the paint film showed no change after being soaked in 5%-10% hydrochloric acid and saturated Ca(OH)2 aqueous solution for 30 days. The paint film also showed no change after 2000 hours of salt spray test.
2.Strong adhesion and excellent toughness: The coating film is hard and has good toughness. Impact-resistant (1cm², 50kg), no cracks, no changes in the coating film for screw family scratches, no cracking or peeling when bent on a φ10mm shaft.
3.It can be used under harsh conditions: After curing at room temperature, it will not be affected when applied in harsh environments ranging from -40℃ to 150℃.
4.Strong closed-cell performance: When this anti-corrosion coating is brushed or troweled and has undergone certain treatments, the coating film is dense and has a high closed-cell rate,All reach 100%, and the paint film has extremely strong corrosion resistance
5. It has extremely strong adhesion: It can be brushed onto various materials such as metal steel, cement, wood, tiles, zinc-coated pipes, stainless steel, etc.
Epoxy coating
It cannot be applied to sensors (made of alloy steel or stainless steel), but Vitworth special anti-corrosion coatings can provide an additional layer of protection and anti-corrosion for the sensors.
The WT-WS special anti-corrosion paint adopts a two-coat anti-corrosion solution of WT-WS 001 special metal sealing coating (primer) and WTIII Type 003 special anti-yellowing anti-corrosion coating (topcoat). Vitvos special coatings are currently the unique technology of Chinese truck scale manufacturers.
Generally, epoxy series anti-corrosion paints or polyurethane are available in the market
All anti-corrosion paint series require four coats of primer, intermediate coat and top coat, or five coats of primer, intermediate coat and top coat. The total dry film thickness of the coating,It is only about 120μm to 160μm.
The use of WEIGHTWORTH special anti-corrosion paint can better prevent the peeling, rusting and corrosion of the floor scale paint, and extend the service life of the floor scale. If you have any questions about weighing, you can call WEIGHTWORTH. There will be a dedicated business manager to serve you and solve your weighing problems.
