Products Description
The WEIGHT WORTH electronic truck scale (commonly known as the floor scale) is a high-precision and high-stability intelligent weighing system designed for the settlement of bulk goods trade, industrial production control and logistics weighing.
The scale platform is welded with U-shaped steel, equipped with digital load cells and intelligent weighing instruments. It is suitable for heavy-load and harsh working conditions in mines, metallurgy, ports, chemical industries, logistics parks, etc.
It takes into account OIML level III high precision, strong anti-interference and long-term maintenance-free. It is the core equipment for enterprises to reduce costs, increase efficiency and achieve compliant measurement
Core advantage
✅ Industrial-grade sturdy structure, no deformation under heavy load
• U-shaped steel patented structure: Orthogonal anisotropic design, fully automatic continuous key welds, overall rigidity up to 1/1000 standard, extremely strong torsional and lateral force resistance.
• Heavy-load durability verification: Full-load high-frequency fatigue testing, suitable for long-term heavy loads ranging from 20 to 200 tons, with a lifespan increased by over 50% compared to traditional products.
• Anti-corrosion and anti-rust process: Overall shot blasting + anti-corrosion coating, stainless steel sealed sensor, IP68 protection, not afraid of damp, dusty, acidic and alkaline environments.
✅ high-precision digital sensing, zero error in measurement
• OIML Grade III accuracy: Division n=3000, verification division value 10/20/50kg, comprehensive error ≤±0.02%FS, meeting global trade settlement standards.
• Digital signal anti-interference: RS485 bus transmission, with a distance up to 1000 meters, lightning protection (capable of withstanding 80kA surge current), strong magnetic field protection, and high-frequency interference protection.
• Intelligent self-diagnosis: Real-time monitoring of sensor status, automatic fault alarm, no calibration required for sensor replacement, and zero maintenance threshold.
✅ intelligent anti-cheating, data traceable
• AACF Anti-Cheating Technology: Eliminates external signal tampering, weighbridge remote control and other cheating methods to ensure fair trade.
• Full data record: Stores over 500 vehicle numbers/tare weights and 1,000 weighing records, supports one-click display of gross weight/net weight/tare weight, automatic accumulation and report printing.
• Networked management: Connects to computers, large screens, and printers, supports RS232/485 interfaces, and is compatible with unattended weighing systems.
✅ flexible installation, suitable for all scenarios
• Modular scale platform: Standard size 3×9m - 3.4×24m, supports customized length/width, suitable for various types of vehicles such as semi-trailers, dump trucks, and containers.
• Dual installation mode: No foundation pit (above-ground type, simple construction and low cost)/shallow foundation pit (underground type, with the platform surface flush with the ground, safe passage) is available for selection.
Technical Parameters
| Item | Specification |
|---|---|
| Brand | WEIGHT WORTH |
| Model | SCS Digital Series |
| Accuracy Class | OIML Class III, n=3000 |
| Weighing Capacity | 20t/30t/50t/80t/100t/120t/150t/200t |
| Verification Division Value | 10kg/20kg/50kg Optional |
| Platform Size | 3×9m, 3×12m, 3×16m, 3×18m, 3.2×21m, 3.4×24m, Customized |
| Load Cell | C3 Digital Bridge Type, IP68 |
| Display | Backlit LCD Screen, Multi-language Menu |
| Working Temperature | Cell: -30℃~+70℃; Indicator: -10℃~+45℃ |
| Transmission Distance | Up to 1000m |
| Installation Mode | Pitless / Shallow Pit / Pier Mounted |
Products Description
Standard Configuration
Modular U-beam weighing platform
Digital weighing load cells
Intelligent weighing indicator
Stainless steel junction box
Shielded connection cables
Position limit accessories
Optional Accessories
Unattended weighing system, data management software, explosion-proof components, LED remote display, thermal printer.
Why Choose WEIGHT WORTH
Over 10 years professional weighing equipment manufacturing experience, products exported worldwide
Strict quality inspection, all products certified with OIML R76
24-month warranty and lifelong technical support
Customized solution for special working demands
